stellar labs EC4000 - Chapter 3: Crane Assembly Drawings; Base Assembly Diagram (PN 71896)

Stellar
®
EC4000-20 Telescopic Crane Owner’s Manual | Page 19
PN 71896
.YTQNOITPIRCSEDTRAPMETI
10004CE ESAB550051
10255 ROTOM NOITATOR4021D2
3 21151 GASKET MOTOR 008-10056-11
4D1307
CAP SCR 0.50-13X1.25 SHGR8 W/ RED
PATCH
2
5 16655 CAP SCR 0.63-11X4.00 HHGR9 14
6 71897
STOP SLIDING EC4000/EC5000
KINEMATICS
1
419RG TALF 36.0 REHSAW337617
8D1345 FTG CPRSN 0.12NPT/0.25 TUBE2
9D1810 TBE AIR SAEJ844 TYPE A .25 (RM) 2.5
10 22161 FTG 2-2 FP-FP COUPLER STRAIGHT BRASS1
11 56589 ZERK 1/8 NPT STRAIGHT LONG THREAD 1
12 69735
BEARING SWING DRIVE 9 IN EC4000/5000
KINEMATICS
1
MOTOR GASKET SHOWN AS REFERENCE ONLY
6
3
2
4
1
7
5
8
11
10
8
9
12
Base Assembly - PN 71896
Chapter 3 - Assembly Drawings
