stellar labs EC4000 - Cable & Hook Assembly Diagram (PN 50492)

Stellar
®
EC4000-20 Telescopic Crane Owner’s Manual | Page 27
.YTQNOITPIRCSEDTRAPMETI
1 50493PCPLATE SNATCH BLOCK EC40002
2 50387 SHEAVE EC4000 6.75 DIA .31R/1.00THK 1
3 0352WASHER 0.50 USS FLAT ZINC 6
4 5468 NUT 0.50-13 HHGR8 NYLOC 3
5 27810 SPACER 3315 SNATCH BLOCK UHMW 2
6 16607PCSPACER 3315 SNATCH BLOCK 1
7 47868 CAP SCR 0.50-13X2.75 HHGR83
8 9610 WIRE ROPE 0.31 6X19 IWRC-XIP 90FT1
9 9263 PIN .38X3.00 QUICK RELEASE1
1NOT 3-ENARC KOOH8106C01
11 0375 MACHY WASHER 0.75ID 14GA2
1RETTOC 05.2X57.0 NIPPZ4252421
200.1X521. NIP RETTOC4287331
8
13
11
12
11
13
4
3
1
2
10
9
1
5
3
7
6
PN 50492
Cable & Hook Assembly - PN 50492
