stellar labs EC4000 - Mast Assembly Diagram (PN 50368)

Page 20 | Stellar
®
EC4000-20 Telescopic Crane Owner’s Manual
PN 50368
MOUNTING HOLE
7
8
8
7
4
4
16
1
17
15
16
17
11
12
13
14
18
19
6
5
2
3
2
9
23
NOTE:
WINCH CONTROLLER
SHOWN FOR REFERENCE ONLY
2
20
24
8
21
22
8
#50374 MUST
GO IN THIS MAST
8
.YTQNOITPIRCSEDTRAPMETI
10004CE TSAM963051
2C5902 WASHER 0.63 SAE FLAT YELLOW GR812
3 50375 CAP SCR 0.63-11X2.75 HHGR89
4 20362 BUSHING IGUS GFI-1618-08 4
5 0345CAP SCR 0.38-16X1.50 HHGR5 2
2TALF 83.0 REHSAW64306
7 0478 CAP SCR 0.25-20X0.50 HHGR5 3
6SS TALF 52.0 REHSAW7190D8
9 50374CAP SCR 0.63-11X3.09 MOD EC4000 1
11 47411 BRKT OVERRIDE BUTTON EC32001
2TALF 52.0 REHSAW043021
13 0479 CAP SCR 0.25-20X0.75 HHGR5 2
14 42513POWER UNIT 12V EC3200 1
1EPDH 0023CE REVOC5744451
16 0343 WASHER 0.31 USS FLAT ZINC 3
17 0420 CAP SCR 0.31-18X0.75 HHGR5 3
18 0492 CAP SCR 0.38-16X0.75 HHGR51
19 5870 WASHER 0.38 STAR EXTERNAL 1
20 51281CAP SCR 0.63-11X2.75 SHSS 2
21 51896 BRKT COVER EC CRANES1
22 C6021CAP SCR 0.25-20X0.75 BTNHD SS 1
23 30659 NUT 0.25-20 HH NYLOC SS 1
24 C6022CAP SCR 0.25-20X1.00 BTNHD SS 1
Mast Assembly - PN 50368
