EC4000-20 Telescopic Crane Owner’s Manual | Page 1
Chapter 1 - Specications
Model EC4000-20ft Version Crane
SPECIFICATION SHEET
Crane Rating: 16,000 ft-lb (2.21 TM)
Standard Boom Length: 10’ (3.05 m) from CL of Crane
Boom Extension: 1st stage: Hydraulic 60” (152.4 cm)
2nd stage: Manual 60” (152.4 cm)
Maximum Horizontal Reach: 20’ (6.10 m) from CL of Crane
Maximum Vertical Lift: 21’ 3” (6.48 m)
(from crane base)
Boom Elevation: -5 to +80 degrees
Stowed Height: 29.53” (75 cm)
(crane only)
Mounting Space Required: 19” x 19” (48.3 x 48.3 cm)
Approximate Crane Weight: 1180 lbs (535 kg)
Controls: Radio control standard for all functions.
Winch Specifications
Rope Length: 90 ft (27.4 m)
Rope Diameter: 5/16” (.79 cm)
Line pull speed: 15 ft/min (4.6 m/min)
Max. single part line: 2000 lbs (905 kg)
Max. double part line: 4000 lbs (1815 kg)
Rotation: 410 degree power
(worm gear)
Lifting Capacities: 4000 lbs @ 4’ (1814 kg @ 1.22 m)
1065 lbs @ 15’ (480 kg @ 4.57 m)
800 lbs @ 20’ (360 kg @ 6.1 m)
Power Supply Required: 12 volt power unit
(2.0 gpm @ 2300 psi)
(7.57 lpm @ 159 bars)
*Subject to change without notification
