Operating the crane without
the truck engine running could allow the truck
battery to be discharged below levels required
for starter cranking power.
NOTICE
AUX
BAT
CRANE HARNESS
+
-
Electronic
Switch
AUX BATTERY
GND
BATTERY SEPARATOR
(NOT SUPPLIED)
STELLAR #71443
(INSTALL TO MFR STANDARDS)
FUSE HOLDER
#32523
FUSE
(SEE CHART)
(STELLAR SUPPLIED)
TO CHASSIS HIGH POWER
GROUNDING LOCATION
TO CHASSIS BATTERY +
200A BREAKER
(NOT SUPPLIED)
STELLAR #119639
2GA
EC3200
250A
WIRE GA:
CRANE:
FUSE:
2GA
EC4000
250A
2GA
EC5000
250A
1/0
EC6000
300A
CRANE PWR WIRE
(SEE CHART)
87A
86
85
30
87
SAFETY BRAKE
(GROUND SIGNAL)
SWITCH POWER
15 AMP
OPT 1
OPT 2
GROUND
POWER
*LOCATE AUX BATTERY AS
CLOSE TO CRANE AS POSSIBLE
-CRANE-
-CAB OR CRANE COMPARTMENT-
POWER SOURCE FOR
RADIO REMOTE
-UNDERHOOD-
GROUND POST
START MOTOR
SOLENOID
Solenoid Torque Spec
Large Nuts: 35 in-lbs
Small Nuts: 15 in-lbs
WIRE & FUSE SIZING:
PARK INTERLOCK KIT
(NOT SUPPLIED)
STELLAR #123502
To Next Page
