Main Boom Assembly - PN 53223 Parts List
PN 53223
ITEM PART DESCRIPTION QTY
1 53224 INNER BOOM EC6000 1
2 72602 CORD REEL ASM 15/21 FT CRANE 1
3 340 WASHER 0.25 USS FLAT 3
4 C5606 CLAMP 0.25 BLK VINYL 1
5 43845 CAP SCR 0.25-20X0.38 HHGR5 2
6 C1592 ZERK 1/8 NPT STRAIGHT 1
7 42508 WEAR PAD 0.50X1.50X2.00 1
8 D0790 WASHER 0.50 FLAT GR8 4
9 13815 PLATE ANGLE INDICATR PC BLACK 2
10 C6106 NUT 0.50-13 HHGR5 NYLOC 2
11 16067 BUSHING QSI-2426-16 2
12 21810 BUSHING GSI-2426-12 1.50X0.75 1
13 53232 CYLINDER 4.00X21.00 1
14 53231CR PIN 1.50X6.88 D&T ZC 2
15 7403 PIN CAP 0.44X2.50X0.19 YZ 4
16 C6353 WASHER 0.38 FLAT GR8 6
17 9843 CAP SCR 0.38-16X0.75 HHGR8 6
18 42516CR PIN 1.00X5.13 D&T ZC 1
19 9320 PIN CAP 0.44X1.75X0.19 YZ 2
20 53518CR PIN TEAR DROP 1.50X2.19 ZC 1
21 5591 WASHER 0.31 SAE FLAT YELLOW GR8 1
22 53521 CAP SCR 0.31-18X0.75 HHGR8 1
23 D0917 WASHER 0.25 FLAT SS 2
24 480 CAP SCR 0.25-20X1.00 HHGR5 2
25 521 WASHER 0.25 LOCK 4
26 53230 WINCH 3000DC WARN 1
27 50111 CAP SCR 12MMX45MM HHGR8 4
28 42788 WASHER 0.44 SAE FLAT YELLOW GR8 4
29 51168 COVER WEAR PAD EC5000 PC WHITE 2
30 492 CAP SCR 0.38-16X0.75 HHGR5 8
31 346 WASHER 0.38 USS FLAT 8
32 523 WASHER 0.38 LOCK 8
33 51169 WEAR PAD 0.50X1.00 RND 4
34 536 NUT 0.44-14 HHGR5 1
36 C0082 CLAMP 0.75 BLK VINYL 1
37 479 CAP SCR 0.25-20X0.75 HHGR5 1
38 333 NUT 0.25-20 HHGR5 NYLOC 1
REV. G
NOTES:
HARDWARE KIT: 97590.
RADIO RECEIVER SHOWN AS REFERENCE ONLY.
