stellar labs EC6000 - Extension Boom Assembly - PN 53264 Parts List

Stellar
®
EC6000 Telescopic Crane Owner’s Manual PN: 65779 | Page 33
Extension Boom Assembly - PN 53264 Parts List
PN 53264
ITEM PART DESCRIPTION QTY
1 50612 EXT BOOM 1ST EC5000 1
2 53265 CYLINDER 2.00X60.00 EC6000 1
3 D0790 WASHER 0.50 FLAT GR8 9
4 10172 CAP SCR 0.50-13X1.00 HHGR8 ZY 1
5 42509 WEAR PAD 0.38X1.38X1.50 2
6 50617 EXT BOOM 2ND EC5000 1
7 42524CR PIN 0.75X2.50 COTTER ZC 2
8 42977 PIN HITCH 0.63X4.00 2
9 50387 SHEAVE EC4000 6.75 DIA .31R/1.00THK 2
10 50386 PLATE CRADLE EC4000 PC BLACK 1
11 0423 MACHY WASHER 0.75ID 10GA 4
12 37824 COTTER PIN .125X1.00 4
13 42978 FLAT BOOM STOP EC3200 PC BLACK 1
14 0507 CAP SCR 0.50-13X4.50 HHGR5 2
15 27710 SPRING ANTI 2 BLOCK CRADLE A2B 2
16 C6106 NUT 0.50-13 HHGR5 NYLOC 3
17 0352 WASHER 0.50 USS FLAT ZINC 2
18 35105 SWITCH LIMIT E1117-B9111-6C 1
19 D0178 WASHER #10 SAE FLAT ZINC 2
20 43846 SCREW #10-24X0.38 SH SS 2
21 0505 CAP SCR 0.50-13X3.50 HHGR5 1
22 D0561 CAP SCR 0.25-20X0.50 BTNHD SS 2
REV. A
NOTE: HARDWARE KIT: 92509
