6.2.3 List of parameter U of panel operator
Parameter U is used to display 16 real-time parameters of inverter. Pay attention
that those parameters cannot be modified but displayed. Table 6.5 describes the
function codes and names of those parameters.
表 6-5 list of parameter U
Function
Code
Function
Name
Instruction
Unit
Factory
setting
U00 Feedback Speed Monitor of the motor feedback speed rpm ×
U01
Reference
Speed
Speed setting values instruction 0 rpm ×
U02
Temperature of
radiator
Monitor Temperature of radiator ℃ ×
U03 Speed deviate
Deviation between the Feedback Speed
and Reference Speed Values
rpm ×
U04 Output Current Monitor of the output current A ×
U05 Torque offset × ×
U06 Output Torque
Monitor of the output torque of vector
control
% ×
U07
DC BUS
Voltage
Monitor of the DC voltage of inverter
interior main loop
V ×
U08
Door width of
real time
running
Door width of real time running P ×
U09
Current position
of door
Current position of door P ×
U10
Percentage of
openning
Percentage of openning ％ ×
U11 Input signal Next page × ×
U12 output signal Next page × ×
U13 spare × ×
U14 spare × ×
U15 spare × ×
