iAStar Frequency Inverter For Elevator Door Machine manual Instructions
57
7.2 debugging of control terminals
7.2.1 Wiring of control terminals
Details shown in chapter 3
7.2.2 Debugging steps
1、confirm wiring is correct, turn on the power
2、set parameters，shown in table7-1 and 7-2，save parameters（set F00 = 199 to
save）；
3、set torque and PID parameters shown in table 7-3；
4、debugging door running curve parameters are shown in table 7-4
(a) turn on the power, push the door from position of door open limit of closing
door (or from position of door close limit of openning door) check input of U11, if no
signals, check input limit swich or set F36
(b) input the door-opening or door-closing signal, and then the door will close or
open at a low speed, until the door door close limit or opening limit, and only after the
relay of door close limit or opening limit signal is given, inverter can run normally.
Input door-opening or door-closing signal, the door will run normally.
(c) set the top speed of door-opening and door-closing
If transmit proportion is 1:1，top speed is about 200rpm
If transmit proportion is（4～6）:1，top speed is 500～600rpm。
(d) input closing signals：
If Door rammed, increase deceleration of closing F20
If crawling distance is too long or door can not close completely，decrease
deceleration of closing F20
If door blade was net fraped, increase low speed of closing-stopped F16。
Increasing acceleration of closing F19 will accelerate door-closing
(e) input openning signals：
If Door rammed, increase deceleration of openning F18
If crawling distance is too long or accelerateing process happen after decelerating
closing，decrease deceleration of openning F18
Increasing acceleration of openning F17 will accelerate door-openning
(e) through modifying F30、F31、F33, holding torque of closing and openning
can be realized.
(f) modifying F06 will adjust the position of opening door, and the adjustment of
opening door ‘s percentage can be realized by modifying F05
