4 Function parameter list
4.1 Function parameter list
Detailed function, parameter range and pre configured parameters are shown in the
following form.
Table 4-1 FUNCTION PARAMETER LIST
Function
code
Names of parameter Parameter range Unit
Factory
setting
F00
Version No.&function
settin
1/199 / 9999 × 25015
F01 Language selection 0 / 1 × 1
F02 Input mode selection
0 / 1 / 2 / 4 / 99
× 0
F03 Control mode selection 0 / 1 / 2 / 3 × 1
F04 Door width 0 ~ 60000 × 16000
F05
Percentage of door
openning
0 ~ 100 % 100
F06
Adjustment of door open
limit
0 ~ 400 × 180
F07
Permillage of door open
limit
0.0 ~ 100.0 % 99.0
F08
Permillage of door close
limit
0.0 ~ 100.0 % 1.0
F09 Not used × × 0
F10
Frequency switching
point
0 ~ 10.00 Hz 2.00
F11
Low speed of starting to
open
0 ~ 300 rpm 70
F12
Low speed of starting to
close
0 ~ 300 rpm 60
F13 High speed of openning 0 ~ 1500 rpm 500
F14 High speed of closing 0 ~ 1500 rpm 400
F15
Low speed of stopping
to open
0 ~ 300 rpm 30
F16
Low speed of stopping
to close
0 ~ 300 rpm 20
To Next Page
