iAStar Frequency Inverter For Elevator Door Machine manual Instructions
27
5 specifications of function parameters
Detailed specifications of function code and parameter setting:
F00 Version display Range：1/199/9999
Display the soft version of inverter.
F00 = 1，clera current torque holding.
F00 = 199，parameter saving, set F00=199 to save parameters each time after you
change them, otherwise the parameters will return to the original value before your
changing after the power is off. The soft version will display after your setting.
F00 = 9999，all parameters resets to factory setting. Then function parameter resets to
display the soft version.
F01 Language selection range：0/1
F01 = 0，English
F01 = 1，Chinese
F02 Input mode selection range：0/1/2/4/99
F02 = 0，Input running signals from external terminals
F02 = 1，Input running signals from CAN BUS
F02 = 2，nput running signals from operator panel
F02 = 4，automatic run（only for factory test）
F02 = 99，Self-learning width of door
Note：When F03 = 0 / 1 / 2，set F02=99 to start self-leaning；If F03 = 3，
self-leaning will not proceed. Set F00=199 after self-leaning to save the
parameters.
F03 Control mode selection range：0/1/2/3
F03 = 0，encoder vevtor control mode，encoder pulses
≧
200ppr
F03 = 1，encoder V/F control mode, excluding openning or door close limit
signals, encoder pulses
≧
20ppr
F03 = 2，encoder V/F control mode, including openning and door close limit
signals, encoder pulses
≦
20ppr
F03 = 3，terminals V/F control mode, including 4 swiches（limit position of door
openning and closing, decelerating of door openning and closing）
F04 Door width range：0-60000
Served in pulse parameter setting matching door-width obtained in self-learning.
F05 Percentage of door openning range：0-100
Percentage of door openning distance in door width.
