STEP
iAStar Frequency Inverter For Elevator Door Machine manual Instructions
37
F3
F3
Changing password in mode 【Function Select】,press F3 to enter
interface of password modifying
Key your new password, then press enter to confirm，modifying
succeed will appear. Available password range is 0～9999。
6.1.2 Operation
The digital operator displays【software version of operator】, 【Init Menu】a few
seconds after power on
▼ Power On and Initialization
The process of initialization will last about 5 seconds after power on. After
initialization , the digital operator enters
【Run State】mode.
▼ Operation Mode
Besides【Init Menu】, the digital operator provides three operation modes of 【Run
State】, 【Function Select】and【Para Revises】.
▼ 【running state】
【Run State】mode is used to display 16 real-time parameters of inverter. Pay
attention that those parameters cannot be modified but displayed. Table 6.3 describes
the function codes and names of those parameters.
Table 6-3 parameter names and function codes
Function
Code
Function Name Instruction
Unit
Factory
setting
U00 Feedback Speed Monitor of the motor feedback speed rpm ×
U01
Reference Speed
0
Speed setting values instruction 0 rpm ×
U02
Temperature of
radiator
Monitor Temperature of radiator ℃ ×
U03 Speed deviate
Deviation between the Feedback
Speed and Reference Speed Values
rpm ×
U04 Output Current Monitor of the output current A ×
U05 Torque offset × ×
U06 Output Torque
Monitor of the output torque of vector
control
％ ×
To Next Page
