Shanghai STEP Electric Co., Ltd.
38
U07 DC BUS Voltage
Monitor of the DC voltage of inverter
interior main loop
V ×
U08
Door width of
real time running
Door width of real time running P ×
U09
Current position
of door
Current position of door P ×
U10
Percentage of
openning
Percentage of openning ％ ×
U11 Input DI1- DI12
Confirm input status of terminals
DI1- DI8
U11 = 00000000
DI1：input signal of door openning
DI2：input signal of door closing
DI3：signal of door closing in low
speed
DI4：signal of door open limit
DI5：signal of door door close limit
DI6：signal of decelerating openning
DI7：signal of decelerating closing
DI8：spare
× ×
U12 Output DO1-DO6
Confirm output status of terminals
DO1- DO4
U12＝000000
DO1：door door open limit
DO2：door door close limit
DO3：door closing blocked
DO4：fault signals
× ×
U13 spare × ×
U14 spare × ×
U15 spare × ×
