Table 4-1 FUNCTION PARAMETER LIST
Function
code
Names of parameter Parameter range Unit
Factory
setting
F17
Acceleration of
openning
1 ~ 30 × 6
F18 Deceleration of closing 1 ~ 30 × 4
F19 Acceleration of closing 1 ~ 30 × 4
F20 Deceleration of closing 1 ~ 30 × 4
F21
Deceleration of
crash-stop
1 ~ 50 ×
10
F22
Crawl distance of
openning
1 ~ 30 % 4
F23
Crawl distance of
closing
1 ~ 30 % 4
F24
Deceleration point of
openning
50 ~ 100 % 67
F25
Deceleration point of
closing
1 ~ 50 % 40
F26 Close delay 0 ~ 30000 ms 0
F27 Open delay 0 ~ 30.000 S 0
F28
Speed of closing retiring
cam
0 ~ 300 rpm 30
F29
torque limit of closing
1 ~ 300
％
200
F30
Holding torque of
openning
0 ~ 30 × 0
F31
Holding torque of
closing
0 ~ 30 × 0
F32 Torque boost 0 ~ 30 % 20
F33 Speed of Holding torque 0 ~ 90 rpm 60
F34
V/F low-speed
compensating torque
0 ~ 40 % 20
F35 Process of door-blocked 0 / 1 / 2 / 3 / 4 / 5 × 0
