(f) modifying F06 will adjust the position of opening door, and the adjustment
of opening door ‘s percentage can be realized by modifying F05
(g) modifying F07、F08 will adjust the relay out put point of door opening
toposition and door close limit. (percentage of position)
(h) if door was blocked at the first running, cut the power and check if the door is
locked by something
Table 7-4 Referenced
value of parameters
Function
code
Name of parameters Referenced value
F04 Door width 20000
F05 Percentage of door openning 100
F06 Adjustment of door open limit 200
F07 Permillage of door open limit 99.5
F08 Permillage of door close limit 0.5
F11 Low speed of starting to open 70
F12 Low speed of starting to close 60
F13 High speed of openning 300
F14 High speed of closing 200
F15 Low speed of stopping to open 50
F16 Low speed of stopping to close 30
F17 Acceleration of openning 6
F18 Deceleration of closing 6
F19 Acceleration of closing 5
F20 Deceleration of closing 5
F22 Crawl distance of openning 4
F23 Crawl distance of closing 2
F24
Deceleration point of openning（void
when F03=3）
60
F25
Deceleration point of closing（void
when F03=3）
40
F30 Holding torque of openning 7
F31 torque limit of closing 7
