Aluminum T-Slot Table (optional)
The aluminum T-slot table consists of individual aluminum panels of 19 mm strength with integrated T-
slots M6 in a distance of 50 mm. The individual T-slots run in X direction.
The aluminum T-slot table can be inserted in the upper as well as in the lower guide slot of the Y-axis
and, thus, allows a change of the passage height from 135 mm to 195 mm.
90° T-Slot Table (optional)
The optional 90° T-Slot Table can be easily installed instead of one of the table elements of 100 mm
width and makes working with your CNC system even more flexible.
Thanks to the integrated T-slots in the horizontal as well as in the perpendicular, the 90° T-slot table is
perfectly suited for the vertical clamping of workpieces.
Arbitrary Combination of the different machine table solu-
tions
The separately available machine table elements can be individually combined. Please the „Configura-
tion Help Machine Table STEPCRAFT M-Series” for a comprehensive explanation.
Freestyle Milling
TM
A unique feature of the STEPCRAFT M-Series is Freestyle Milling
TM
. With Freestyle Milling™, the ma-
chine table is removed completely so that the workpiece material under the machine can be pro-
cessed. The maximum available milling depth is 25 mm.
Note: For the safe positioning of the machine when using Freestyle Milling™, we strongly recommend
the use of the optional vacuum panels (item no. 12032, 12033, 12034).
Clamping the Workpiece
The workpiece can be secured directly on the machine table using clamping devices such as the
clamping set.
If you want to mill through the material and produce cutouts, we recommend the use of suitable mate-
rial as spoil board. It is placed under the workpiece and protects the machine table from potential dam-
age.
The workpiece should be sufficiently clamped to prevent it from unintentional shifting during pro-
cessing.
Never hold the workpiece with your hands during the operating process. There is a high risk of serious
injury!
The maximum workpiece size results of the maximum clamping length and clamping width:
