- 49 -
CLRS Series RS485 Closed Loop Stepper Drive User Manual
6.2 Basic Operation of Serial Port Tools Software
This is to control the motor through RS485 communication, user can realize the movement of the motor by sending
commands to the corresponding registers.
6.2.1 Preparation and Steps
(1) RS485 tuning cable
RS458 to USB (User-provided)
RS485 DB9 to RJ45 (User-provided)
