CLRS Series RS485 Closed Loop Stepper Drive User Manual
4.3.2 Input and Output Parameters
(1) SI1 is set to enable by default, N.C
(normally closed).
(2) Other inputs are N.O (normally open) by
default.
(3) The value of bit7 of each input register is
set normally closed or normally open, bit7=1
is normally closed, bit7=0 is normally closed
(1) All outputs are N.O (normally open) by
default,
(2) The value of bit7 of each input register is
set normally closed or normally open, bit7=1
is normally closed, bit7=0 is normally closed.
Note: (1) If the input or output function is set repeatedly, only after the restart drive can detect it.
(2)When input functions are configured, it is effective after clicking save and restart drive.
Digital Input port function assignment:
Normal-open (N.O); Normal-closed (N.C).
4.3.3 Smooth Filter Time Setting for Digital Inputs
This section describes the setting of the value of each bit of the registers of the 7 inputs, where the filtering time is
set by the high 8 bits.
Set value of low 8 bits:
