More than one radio may work for a given radio setting. For example, the Kenwood
setting works for Elecraft and the FT9000 setting works for the FT3000 and FT6000. If
radio model is not listed, check transceiver interface manual. Finally, some radios require
settings to be changed to get their CAT port to work.
Radio
Station ground
Controller
Cable for controller and radio to
communicate. Cable typ is radio-dependent.
Please refer to rig instruction manual
Data In/
Radio
Data
Out
Data
Out
Transceiver Interface to Radio
