21
Radio
Station ground
Controller
Shown below are two steppIR controllers stacked
using a cable. Also being used is the Y cable to link
both controllers to the radio and PC
Computer
Data In/
Radio
Controller
Data In/
Radio
Data
Out
Data In
Data
Out
Y-cable is used to link controller and radio to
a PC. Used with logging programs.
Controllers Stacked with Y-cable
