SteppIR SDA 2000 OptimizIR - Transceiver Interface to PC Only

22
Station ground
Controller
Computer
Data In/
Radio
Data In
Data
Out
This configuration shows the controller linked to the PC with a cable.
This can be done if station has many different radios linked to PC.
This will allow user to control everything from the PC
Transceiver Interface to PC only
