SPIKE SYSTEM AND NODE GUIDE
DEADPOOL PRO MANUAL 500-55K1-01
© MARVEL
MARVEL.COM
LIGHT REFERENCE CONTINUED
3.5 MOTOR REFERENCE
ID Name Node Node
Ext.
Conn. Ret.
Pin
Ret. Wire Src.
Pin
Src. Wire Location Type Light
Color
Address Part Number
152 Mid Left GI 8 - CN15 6 RED BLK 2 YEL RED Playeld G.I. White 8-LP-1 112-5034-08 (WHT)
112-5034-02 (RED)
153 Mid Right GI 8 - CN15 7 BLU BLK 3 YEL BLU Playeld G.I. White 8-LP-2 112-5034-08 (WHT)
112-5034-02 (RED)
515-1895-01 (Lil'
Deadpool Spot)
154 Upper Left GI 9 - CN15 5 GRN BLK 1 YEL GRN Playeld G.I. White 9-LP-0 112-5034-08
155 Upper Right GI 9 - CN15 6 RED BLK 2 YEL RED Playeld G.I. White 9-LP-1 112-5034-08
156 Backpanel GI 9 - CN15 7 WHT BLK 3 YEL BLK Backpanel G.I. White 9-LP-2 112-5034-08
112-5034-08F
157
158
159
160 Dazzler Spinner Flash 9 a - LED10 - - - Playeld Flash White 9-LP-19 520-8046-00
161 Wolverine Spinner Flash 9 b CN3 9 ORG WHT 1/2/3 RED Playeld Flash White 9-LP-50 113-5045-08
162 Truck Flash 8 c CN2 8 BRN BLK 1/2/3 RED Playeld Flash White 8-LP-30 520-7000-00
163 Pop Bumper Flash 9 b CN1 6 BRN ORG 1/2 RED Playeld Flash White 9-LP-40 113-5045-08
164
165 T. Rex Backpanel Flash 9 - CN14 6 BRN GRN 7/8 YEL Backpanel Flash White 9-LP-3 520-7000-00
166 Juggernaut Backpanel
Flash
9 - CN14 5 BRN BLU 7/8 YEL Backpanel Flash White 9-LP-4 520-7000-00
167 Mystique Backpanel Flash 9 - CN14 4 BRN VIO 7/8 YEL Backpanel Flash White 9-LP-5 520-7000-00
168 Sabretooth Backpanel Flash 9 - CN14 3 BRN GRY 7/8 YEL Backpanel Flash White 9-LP-6 520-7000-00
169 Megalodon Backpanel Flash 9 - CN14 4 BRN WHT 7/8 YEL Backpanel Flash White 9-LP-7 520-7000-00
170 Eject Flash 9 b CN1 7 BRN YEL 1/2 RED Playeld Flash White 9-LP-41 113-5045-02
171 Bottom Pop Bumper 9 b CN1 3 BRN RED 1/2 RED Playeld Flash White 9-LP-37 520-8059-00
172 Left Pop Bumper 9 b CN1 4 BRN BLK 1/2 RED Playeld Flash White 9-LP-38 520-8059-00
173 Right Pop Bumper 9 b CN1 5 BRN 1/2 RED Playeld Flash White 9-LP-39 520-8059-00
174
175
176
177
178
179
MOTOR A Coast Brake Brake Dir. 1 Dir. 2
x-LP-0 Enable A H L L L L
x-LP-1 Control 1A H L H L H
x-LP-2 Control 2A H L H H L
L/Low=Lamp On
H/High=Lamp Off
MOTOR B Coast Brake Brake Dir. 1 Dir. 2
x-LP-3 Enable B H L L L L
x-LP-4 Control 1B H L H L H
x-LP-5 Control 2B H L H H L
x=Node # L/Low=Lamp On
H/High=Lamp Off
