Z001019/0_6_July 2008 Page ENGINE - 55
01 ENGINE
SERVICE MANUAL MARINE ENGINES
05.03 ill.5
4 Loosen locking screw (SW22) (ill.5), remove sealing
ring, pull out control rod to the back.
NOTE: Connection of lefthand thread screws
and control links to be opened three
times only.
5 Adjust control link (mass equalization),
refer to 03.02.04.
6 Adjust control, refer to 01.00.03.
7 Calibrate rack position, refer to 06.10.03
