STEYR 6 CYLINDER User Manual

01 ENGINE
Page ENGINE - 82 Z001019/0_6_July 2008
SERVICE MANUAL MARINE ENGINES
01.13 ENGINE OIL COOLER
01.13.01 Replace engine oil cooler
Preparation: Empty closed cooling circuit,
05.00.02
Remove tandem cooler
05.01.06
1 Loosen hose clamp (ill.1/pos.1) on oil cooler.
6 Loosen fixing nut (ill.2) of oil line (SW22).
7 Loosen 4 allen head screws (SW6), remove cooler.
13.01 ill.2
13.01 ill.3
C
1
13.01 ill.1
