GENERAL
Page GENERAL-16 Z001019/0_8_Octobre 2011
SERVICE MANUAL MARINE ENGINES
ToC
A 4.2 Technical data and overview 6 cylinder engines
MAKE STEYR M 16 TCM, TCAM
type MO126M28 MO166K28 MO196K35 MO236K42
displacement 3200 cm³
piston displacement 85,0 x 94,0 mm
number of cylinders 6-cylinder in-line engine (position of cyl. 1 at vibration damper side)
ignition order 1 - 5 - 3 - 6 -2 - 4
sense of rotation, seen from front right
compression ratio 17,5 : 1
full-load speed range (rpm) 2600 - 2800 2600 - 2800 3300 - 3500 4000 - 4300
idle speed 630 rpm. (adjustable)
injection pump - nozzle with modelling needle control
and electronic control
fuel acc. to CEC RF-03-A-84 (DIN EN 590) Cetan >49; diesel fuel
No. 2-D, temperature above -7°C; No.1-D, temperature below -7°C
fuel filter P/No. 2177745/1
fuel filter location suction-sided
air filter MO126 - P/No. 2178992/0; all other 6 Cyl. - P/N 2178992/1
oil pressure above 2000 rpm. 400 - 700 kPa (60 - 100 PSI) microprocessor controlled
filling capacity motor oil approx. 10,0 l engine housing (incl. approx. 1 l oil filter contents)
specification motor oil SAE 5W-50/ACEA B4-02/API CF or 10W-40/ACEA, E4, E5, E7,
API CF / P/N0. Z010058/0
oil and oil filter change intervals*) every 150 operating hours and/or once per season
oil filter P/No. 2178582/1
oil filter location suction-sided
electric charging system 14 V / 90 A alternator with transistorized voltage regulator
cooling system dual cooling circuit; thermostat-controlled, pressurized cooling
circuit; circulating pump with heat exchanger on engine; governor
pump, external raw water circuit to heat exchanger
coolant capacity 13,2 liters
coolant STEYR MOTORS engine coolant - 36 C°
P/No. Z011785/0
*) extended periods to be evaluated upon application and type of usage
STEYR MOTORS GmbH. reserves the right to make changes without notice or obligations.
**) Efficiency of gearbox = 97,0%, efficiency of Z-drive = 95,5%
rated power acc. EN ISO 8665:2006
(impeller **) KW / HP
Jet - Drive / Inboard
Z - Drive
87 / 117
86 / 115
116 / 156
115 / 154
136 / 182
134 / 179
165 / 221
162 / 218
