Z001019/0_6_July 2008 Page ELECTRICAL SYSTEM - 39
06 ELECTRICAL SYSTEM
SERVICE MANUAL MARINE ENGINES
06.06.04 Indication and Cancellation of memorized sensor and circuit faults
Selection and clearing of stored error codes:
Procedure:
* Ignition — OFF
* Connect Tool VR00135/1 to Diagnostic Outlet Plug ( X 23 ) – see 06.03 ill.1
* Ignition — ON
Note: The program changes automatically to indication of error codes.
If no error code is stored, only repeating control code reading “ CODE # 12 “ will be displayed.
Possible memorized codes are indicated as shown in the previous illustrated example ( blinking 3x
CODE # 12 i. e. 3x ERROR CODE # 14 etc. ) The sequence will be prolonged with additional codes if more
then one ERROR CODE is stored.
See Table – ERROR CODES for description
* To delete a determined ERROR CODE from the Engine Management System concentrate for the 3
rd
times
flashing the desired ERROR CODE. While this ERROR CODE is displayed the third time the button ( Tool
VR00135/1 ) must be pushed and kept in this position ( contact open ).
* The indication on the Check Engine Light changes to a fast blinking of the lamp ( app. 4 times per
sec. ). During this rapid flashing light the push button must be released ( close contact after app. 2
sec.) to delete this ERROR CODE.
Note: Any other ERROR CODE have to be selected and cleared individually following the above
mentioned procedure to delete a determined ERROR CODE.
Note: An ERROR CODE can only be deleted if no defect exists in this circuit. In case of a present active
failure, the ERROR CODE keeps reappearing until the problem has been repaired and the circuit is
properly working again.
* Disconnect Tool VR00135/1 from Diagnostic Outlet Plug ( X 23 ) to exit from error code display.
Note: Watch indication of the Check Engine Light and the Warning Horn after ignition contact. If all
ERROR CODES are deleted from the Engine Management System the indication resumes to 0.7 sec.
function test of Check Engine Light and the Warning Horn.
For more details see Chart – Operating Conditions - Instrument panel.
If more then one error code is stored in the Engine Management System the indication sequence will be
continued blinking additional stored error codes. To delete a memorized error code see description Indication
and Cancellation of memorized sensor and circuit faults.
For a description of the possible error codes refer to enclosed Table – Error Codes
ATTENTION: To exit from Error code indication. Tool VR00135/1 must be removed
( connection between Pin 1 to Pin 2 opened ) before ignition is turned ON again.
