Page ENGINE - 14 Z001019/0_6_July 2008
01 ENGINE
SERVICE MANUAL MARINE ENGINES
NOTE: If the index value of engine timing
should not correspond to the allowed
value, follow the instructions as per
item 24.
31 In case of correct index value of engine timing,
tighten hexagon nut of camshaft sprocket SW 30
with 240 +/-12 Nm by holding up with special tool No.
2300711/0.
32 ATTENTION: The following torques are to be
checked again:
1 Torque on hexagon nut of camshaft sprocket
SW 30 240 +/-12 Nm.
2 Fillister socket head screw SW 8 of timing
belt tensioner at 45 +/-4 Nm.
3 3 TORX screws on vibration damper with
135 +/-4 Nm.
33 Remove locking pin on crankshaft.
