Release 00 - 03/2018
Engine RS100 - RSC100
page 11
Service manual
3. TECHNICAL DATA AND SPECIFICATIONS
3.7. Table of Tightening torques
Chapter Ref. Description of screw Tightening torques
5 Assembly xing nut 8 - 10 Nm
5 Tank xing screw 8 - 10 Nm
6 Fixing nuts, starter assembly 8 - 10 Nm
6 Starter screw 4 - 6 Nm
8 - 9 Fixing nuts carburettor and lter 6 - 8 Nm
10 Support screw, governor assembly 8 - 12 Nm
11 - 14 Spark plug tightening torque 16 - 20 Nm
11 Fixing screw reel 8 - 12 Nm
11 Coil xing stud 8 - 12 Nm
12 Brake support screws 8 - 12 Nm
13 Mufer xing nuts 8 - 10 Nm
13 Mufer xing screw 8 - 10 Nm
14 Screws valve cover 7 - 9 Nm
14 Fan xing nut 60 - 70 Nm
14 Blow-by closure plate screw 7 - 9 Nm
15 Union screws under carter and sump 8 - 12 Nm
15 Counterweight governor xing screw 8 - 12 Nm
15 Fixing screws lower connecting rod cap 11 - 13 Nm
P.S. For the coupling tourque of all standard screws refer to the single table.
