Stiga TITAN Series Workshop Manual

1.Replace the timer
2.Replace the timer relay
3.Replace the LED
Replace the shut off valve
Perform relevant action
6.2.2 The starter motor rotates but
the engine does not start
There is fuel in the tank.
The fuel system is bled.*
No other faults in the engine.
No
Yes
Is there 12 V for 1 sec after a
start attempt on the white cable
on the shut off valve?
And:
Yes
Is there 12 V on the red cable
on the shut off valve?
No
No
Do other electrical functions
operate when the ignition is
activated?
Yes
* For venting the fuel system see 5.12 in the user instructions.
No
Double check fuses 2 and
5 (black fuse box)
Replace/adjust the pedal
switch
Is there 12 V for 1 sec after a
start attempt on the front sec-
tion of connector C position 7?
And:
Is there 12 V on the front sec-
tion of connector C position 8
when the ignition is activated?
Yes
WORKSHOP MANUAL
TITAN
Chapter
6 - Electrical system
EDITION
2018
Page
98
