Stiga TITAN Series Workshop Manual

Is there 12 V on the starter
motor pink cable (green con-
nector)?
Yes
Replace/repair the starter
motor
No
Check connector A, clean if
necessary
(between the main wiring
and the left rear wiring)
Replace/adjust the pedal
switch
6.2.1 The starter motor does not
rotate
The starter motor does not rotate.
Start attempts must be made
during metering.
No
Is there 12 V on connection B
on the safety relay?
Yes
No
Is there 12 V between the red
and brown cables on the pedal
switch?
Yes
No
Temporarily connect a cable
between G (yellow cable) on the
safety relay and ground. Does the
starter motor rotate?
No
Replace/adjust the pedal
switch
Yes
No
Replace/adjust the seat
switch
Replace the PTO relay
Replace the safety
breaker relay
Is there 12 V between the red
cable on the pedal switch and
ground?
WORKSHOP MANUAL
TITAN
Chapter
6 - Electrical system
EDITION
2018
Page
97
