Stiga TITAN Series Workshop Manual

2 Chassis and bodywork
General description
To facilitate driving, use of implements and to make it simpler for the user, the machine
is fitted with different types of auxiliary equipment. The auxiliary equipment consist of hy-
draulic, electrical or mechanical devices. The chapter will also cover the cab.
This chapter will give a short description of the functions of the different pieces of equip-
ment and how they are repaired.
WORKSHOP MANUAL
TITAN
Chapter
2 - Chassis and bodywork
EDITION
2018
Page
19
Contents
2.1 Description .........................................20
2.2 Removal/Installation of covers ........21
2.2.1 Removal of engine covers ..............21
2.2.2 Removing the front side cover and the
control panel ...........................................22
2.3 Radiator ..............................................23
2.3.1 Description .....................................23
2.3.2 Dismantling ....................................23
2.3.3 Assembly .......................................24
2.3.4 Topping up with coolant ..................25
2.4 Cab ......................................................26
2.4.1 Changing the windscreen ...............26
2.4.2 Adjusting door ................................27
2.4.3 Windscreen wiper motor .................27
2.4.4 Light setting ....................................28
2.4.5 Removing the cab ..........................29
2.5 Lubrication .........................................30
