Windscreen washer B1
The switch is located in the roof
and is used to activate washing.
Warning beacon B2 (740 DCR)
Obs!
Follow applicable laws regard-
ing use of the warning beacon.
The switch is located in the roof
and is used to start and stop the
rotating warning beacon that is po-
sitioned on the roof of the ma-
chine.
Work lighting B3
Obs!
Follow applicable laws regard-
ing use of the work lighting.
The switch is located in the roof
and is used to switch the work
lighting, positioned on the front of
the machine, on and off.
Windscreen wiper B4
The switch is located in the roof
and is used to start and stop the
windscreen wiper.
B4
B3 B2 B1
WORKSHOP MANUAL
TITAN
Chapter
6 - Electrical system
EDITION
2018
Page
117
