Presshomewithpresssleeve
(1)11158934600.
-Removeassemblysleeve.
-Slideoilsealwithopenside
facingcrankcaseovercrankshaft
stubonclutchside.
•
Presshomewithpresssleeve
(1)41128932401.
Theremainingpartsareassem-
bledinreverseorder.
Important!Greatcaremustbe
takenwhencarryingoutmain-
tenanceandrepairworkortrou-
bleshootingontheignitionsystem.
Thehighvoltagescancause
seriousorevenfatalaccidents!
Troubleshootingontheignition
systemshouldalwaysstartwith
thesparkplug.Refertothema-
nual"Troubleshooting,standard
repairs".
Note:Thetransistorized(breaker-
less)ignitionsystemessentially
comprisestheignitionmodule(1)
andflywheel(2).
-Removeshroud,see3.1.
•
Pullterminaloffsparkplug.
•
Griplegspringwithpliersand
pullitoutofthesparkplugtermi-
nal.
-Unhooklegspringfromignition
lead.
-Slipsparkplugterminalofflead.
-Coatendofignitionlead
(approx.20mm)withoil.
-Fitsparkplugterminalover
ignitionlead.
-Gripendofignitionleadwith
pliersandpullitoutofspark
plugterminal.
11
366RA098 VA
11
22
392RA053 VA
392RA054
VA
11
366RA099 VA
5. Ignitionsystem 5.1 Sparkplugterminal
392RA055
VA
23
