-Pressignitionmoduleagainst
settinggaugeandtightenscrews
toatorqueof4.5Nm.
Remainingpartsareinstalledin
reverseorder.
Removingtheflywheel:
•
Removeclutch,see3.1.
•
Removeflywheel.
Note:Iftheflywheelcannotbere-
movedbyhand,screwpuller(1)
41338930800ontocrankshaft
stubandlightlytaptheendofthe
pullerwithahammer.
Unscrewthepullerwhenthe
flywheelhasloosened.
Flywheel(1)andmagnetpoles(2)
mustnotbecrackedordamaged,
otherwiseanewflywheelmustbe
fitted.
Installingtheflywheel:
Important!Degreasethecrank-
shaftstubandboreoftheflywheel
hubwithcommerciallyavailable
solvent-baseddegreasingagent
notcontainingCFCsorhalocar-
bons,see13.2.
-Fitflywheel.
-Installclutch,see3.2.
392RA066
VA
392RA067 VA
366RA114
1
2
VA
392RA068
1
VA
5.3 Flywheel
26

Stihl FS 80 Specifications

General

Engine Type	2-stroke
Displacement	25.4 cc
Cutting Diameter	420 mm
Shaft Type	Straight
Starter	Recoil
Sound Power Level	106 dB(A)
Fuel Capacity	0.44 liters
Vibration Level	4.5 m/s²
