Stihl FS 80 User Manual

Pickupbody
•
Drawpickupbodyoutoffuel
tankwithassemblyhook(1)
59108938800.
Note:Ensurethatthefuelhoseis
notoverextended.
•
Pullpickupbodyofffuelhose.
-Replacepickupbody.
Thepartsareinstalledinreverse
order.
-Drainfueltank.
-Removestartercover,see6.2.
-Pullfuelhosesoffelbowcon-
nectorsoncarburetor,see8.2.2.
•
Removefueltank.
-Removefuelhosesifnecessary.
Thepartsareinstalledinreverse
order.
•
Pegs(1)mustengageininserts
(2).
Fuelhoses
-Unscrewfuelfillerplugandre-
movewithchain.
•
Drawpickupbodyoutoffuel
tankwithassemblyhook(1)
59108938800.
•
Pullpickupbodyofffuelhose.
•
Pulloutventinghose(1)with
grommet(2).
•
Pulloutfuelhose(3)withgrom-
met(4).
392RA121
1
VA
392RA125
1
VA
392RA122
VA
392RA123
VA
392RA126
VA
392RA124
21
VA
392RA127
1
3
4
2
VA
8.5 Fueltank/
hoses
40

Stihl FS 80 Specifications

General

Engine Type	2-stroke
Displacement	25.4 cc
Cutting Diameter	420 mm
Shaft Type	Straight
Starter	Recoil
Sound Power Level	106 dB(A)
Fuel Capacity	0.44 liters
Vibration Level	4.5 m/s²
