No. Designation Part No. Use Remarks
1 Locking strip for piston 0000 893 5903 Blocking crankshaft
2 Press sleeve 4112 893 2401 Fitting oil seal
(clutch side)
3 Press sleeve 1115 893 4600 Fitting oil seal
(starter side)
4 Assembly sleeve 4112 893 2400 Protecting oil seal
(starter side)
5 Puller 5910 890 4400 Removing oil seals 1)
6 - Jaws (with No. 3.1 + 4 profile) 0000 893 3706
7 Puller 4133 893 0800 Removing flywheel
8 Crimping tool 5910 890 8210 Attaching connectors to electric
wires
9 Assembly drift 1114 893 4700 Fitting and removing piston pin
10 Clamping strap 0000 893 2600 Compressing piston rings
11 Wooden assembly block 1108 893 4800 Fitting piston
12 Carburetor and 1106 850 2905 Testing carburetor and
crankcase tester crankcase for leaks
13 Vacuum pump 0000 850 3501 Testing crankcase for leaks
14 - Nipple 0000 855 9200
15 - Fuel line 1110 141 8600
16 Sealing plate 0000 855 8106 Sealing exhaust port for
leakage test
17 Test flange 1128 850 4200 For leakage test
18 Setting gauge 4118 890 6401 Setting air gap between
ignition module and flywheel
19 Socket, 13 mm 5910 893 5608 Unscrewing clutch and
starter carrier
20 Torque wrench 5910 890 0301 Screw connections 2)
(0.5 to 18 Nm)
5910 890 0302 3)
21 Torque wrench 5910 890 0311 Screw connections 2)
(6 to 80 Nm)
5910 890 0312 3)
22 Screwdriver bit T27x125 0812 542 2104 Tightening down socket head screws
23 Assembly hook 5910 893 8800 Extracting pickup body
24 Assembly tool 5910 890 2208 Fitting hookless snap
rings in piston
25 Press arbor 4119 893 7200 Removing and installing deep
groove ball bearings
26 Assembly tool ZS 5910 007 2220 Removing crankshaft
27 - Sleeve 5910 893 1701
28 - Sleeve 5910 893 1702
29 Assembly tool 5910 890 2202 Installing crankshaft
30 Pliers A10 0811 611 8200 Removing external
circlip on gearbox 4)
13. Special service tools and aids
13.1 Special tools
55
