Stihl FS 80 User Manual

Throttlecablewithoneshort-
circuitwire
-Removethrottletrigger,see7.1.
•
Liftcontactspring(1)upslightly
andremovethrottlecable(2).
•
Unhookcontactspringfrompivot
pin(1)andstudbolt(2).
•
Unscrewstudbolt(1)onslide
control.
•
Removedetentspring(2).
•
Pullslidecontroloutofhandle
moulding.
Thepartsareassembledinrever-
seorder.
-Thecontactspringmustbeinser-
tedcorrectlyintheoutergroove
aroundthestudbolt.
Throttlecablewithtwoshort-
circuitwires
-Refertothemanual"Trouble-
shooting,standardrepairs"with
regardtochangingthethrottle
trigger,interlocklever,contact
springanddetentspring.
7.3 Contactspring/detentspringincontrolhandle 7.4 Throttletrigger/
interlocklever
33

Stihl FS 80 Specifications

General

Engine Type	2-stroke
Displacement	25.4 cc
Cutting Diameter	420 mm
Shaft Type	Straight
Starter	Recoil
Sound Power Level	106 dB(A)
Fuel Capacity	0.44 liters
Vibration Level	4.5 m/s²
