No. Designation Part No. Use Remarks
31 Assembly tool 4126 893 4900 Removing rubber buffer
in AV sleeve
32 Pliers A19 0816 610 1495 Removing external circlip from
clutch drum
33 Screwdriver QI-T27x150 5910 890 2400 For all socket head screws 5)
34 Press arbor 1108 893 4700 Removing and installing
clutch drum
35 Assembly stand 5910 890 3100 Mounting power unit
for repairs
36 - Clamping plate 5910 890 2100
37 Screwdriver T20 5910 890 2301 Separating the handle mouldings
38 Assembly hook 5910 890 2800 Pulling plug out of
protective tube
Remarks:
1) Corresponds to puller 0000 890 4400, but with longer spindle 5910 890 8400.
2) DG/P screws may only be tightened down with a torque wrench.
3) The machine version features an optical/acoustic signalling system.
4) HL 75
5) May only be used to loosen DG/P screws.
56
