MS 194 T
English
51
Rollomatic E Light guide bars
Actual cutting length will be less than
listed bar length.
Carving E guide bars
Actual cutting length will be less than
listed bar length.
Saw chain 3/8" P
Chain sprocket
Saw chain 1/4" P
Chain sprocket
Please enter your saw model, serial
number as well as the part numbers of
the guide bar and saw chain in the
spaces provided. This will make re-
ordering simpler.
The guide bar and saw chain are subject
to normal wear and tear. When
purchasing these parts, always quote
the saw model, the part numbers and
names of the parts.
See "Specifications" in this manual for
the recommended reduced kickback
cutting attachments.
Reduced kickback STIHL guide bars
(with green label)
Bar lengths: 25, 30, 35 cm
(10, 12, 14 in.)
Pitch: 3/8" P (9.32 mm)
Groove width: 1.1 mm (0.043 in)
Sprocket nose: 7-tooth
Reduced kickback STIHL guide bars
(with green label)
Bar lengths: 30, 35, 40 cm
(12, 14, 16 in.)
Pitch: 3/8" P (9.32 mm)
Groove width: 1.3 mm (0.050 in)
Sprocket nose: 9-tooth
Reduced kickback STIHL guide bars
(with green label)
Bar lengths: 30 cm (12 in.)
Pitch: 1/4" P (6.35 mm)
Groove width: 1.1 mm (0.043 in)
Low kickback STIHL saw chain (with
green label)
Picco Micro Mini 3 (61 PMM3)
Type 3610
Pitch: 3/8" P (9.32 mm)
Drive link gauge: 1.1 mm (0.043 in)
Low kickback STIHL saw chain (with
green label)
Picco Micro 3 (63 PM3) Type 3636
Picco Super 3 (63 PS3) Type 3616
Picco Duro 3 (63 PD3) Type 3612
Pitch: 3/8" P (9.32 mm)
Drive link gauge: 1.3 mm (0.05 in)
6-tooth for 3/8" P (spur sprocket)
Low kickback STIHL saw chain (with
green label)
Picco Micro 3 (71 PM3) Type 3670
Pitch: 1/4" P (6.35 mm)
Drive link gauge: 1.1 mm (0.043 in)
8-tooth for 1/4" P (spur sprocket)
Ordering Spare Parts
Model
Serial number
Guide bar part number
Chain part number
