MS 194 T
English
50
EPA / CEPA
The Emission Compliance Period
referred to on the Emissions
Compliance Label indicates the number
of operating hours for which the engine
has been shown to meet Federal
emission requirements.
Category
CARB
The Emission Compliance Period used
on the CARB-Air Index Label indicates
the terms:
Engine
STIHL single cylinder two-stroke engine
MS 194 T
Ignition System
Electronic magneto ignition
Fuel System
All position diaphragm carburetor with
integral fuel pump
Chain lubrication
Fully-automatic speed-controlled oil
pump with rotary piston
Weight
Cutting Attachments
Recommended cutting attachments
conforming with applicable standards
when used on this model chain saw (see
the chapter on "Safety Precautions and
Working Techniques"):
Rollomatic E guide bars
Actual cutting length will be less than
listed bar length.
Specifications
A = 300 hours
B = 125 hours
C = 50 hours
Extended = 300 hours
Intermediate = 125 hours
Moderate = 50 hours
Displacement: 1.94 cu. in
(31.8 cc)
Bore: 1.5 in (38 mm)
Stroke: 1.10 in (28 mm)
Engine power to
ISO 7293: 1.9 bhp (1.4 kW)
Idle speed: 3,000 rpm
Max. permissible
speed (with cutting
attachment): 13,000 rpm
Spark plug (resistor
type): NGK CMR 6H
Electrode gap: 0.020 in (0.5 mm)
Fuel tank capacity: 9.1 fl.oz (0.27 l)
Oil tank capacity: 7.4 fl.oz (0.22 l)
dry, without bar and chain
MS 194 T: 7.3 lbs. (3.3 kg)
Reduced kickback STIHL guide bars
(with green label)
Bar lengths: 30, 35 40 cm
(12, 14, 16 in.)
Pitch: 3/8" P (9.32 mm)
Groove width: 1.1 mm (0.043 in)
Sprocket nose: 7-tooth
Reduced kickback STIHL guide bars
(with green label)
Bar lengths: 30, 35, 40 cm
(12, 14, 16 in.)
Pitch: 3/8" P (9.32 mm)
Groove width: 1.3 mm (0.05 in)
Sprocket nose: 9-tooth
Reduced kickback STIHL guide bars
(with green label)
Bar lengths: 25, 30, 35 cm
(10, 12, 14,in.)
Pitch: 1/4" P (6.35 mm)
Groove width: 1.1 mm (0.043 in)
Sprocket nose: 8-tooth
