0478 111 9953 B - EN
62
● Check:
When the self-propulsion lever is not
actuated, the cable is tensioned slightly
and the machine can be pulled
backwards – the wheels are not
blocked.
14.12 Checking skirting protector
wear
Maintenance interval:
Once a year
● Tilt the lawn mower upwards into the
cleaning position. ( 14.2)
● Measure the thickness of the left and
right skirting protector.
RM650T, RM650V, RM650VE,
RM 650 VS:
A > 8 mm
The housing must be replaced by a
specialist dealer if the thickness is less
than the specification at any point. STIHL
recommends STIHL specialist dealers.
RM 655 RS, RM 655 V, RM 655 VS,
RM 655 YS:
A > 1 mm
The skirting protectors must be replaced if
they are worn down to the limit value on
the underside of the machine or if they no
longer fully cover the housing.
14.13 Storage and periods of
inoperation (winter break)
Store the machine in a dry, locked, dust-
free place. Make sure that it is out of the
reach of children.
Any faults must be remedied prior to
storage. The machine must always be in a
safe operating condition.
Empty the fuel tank and carburettor prior to
storage (e.g. by running empty).
Also note the following points when storing
the machine for long periods (winter
break):
● Clean all external parts of the machine
with care.
● Thoroughly lubricate/grease all moving
parts.
● Unscrew the spark plug (see engine
instruction manual) and pour approx.
3 cm³ of engine oil into the engine via
the spark plug hole. Turn the engine
several times with the spark plug
removed (pull the recoil starter rope).
● Screw the spark plug back in (see
engine instruction manual).
● Perform an oil change (see engine
instruction manual).
RM 650 VE:
● Remove the battery and store
separately from the machine out of
reach of unauthorised persons in a dry,
dust-free and frost-free room.
● Charge the battery completely before
the start of the season. ( 9.5)
15.1 Transport
Carrying the machine:
● Only hold the machine at carrying
handle (1) and at handlebar (2). Always
ensure sufficient distance between the
mowing blade and your body,
particularly your feet and legs.
Securing the machine (lashing):
● Secure the machine on the load floor
using suitable fastening material and
transport upright on its 4 wheels only.
● Fasten ropes or straps to handlebar
console (3) and to housing (4).
Fire hazard!
Keep the spark plug socket away
from the spark plug hole due to the
danger of ignition.
15. Transport
Risk of injury!
Observe the section "For your
safety" before transporting. ( 5.)
Always wear suitable safety
clothing when transporting (safety
shoes, thick gloves).
Always detach the spark plug
socket before lifting or transporting.
For safety reasons, STIHL
recommends lifting or carrying the
machine only with the aid of a
second person.
Before lifting, note the weight
indicated in the section "Technical
specifications".
