Mechanical operating brake
The truck is braked when the operating handle
is released.
The mechanical brake engages when the tiller
is positioned in areas (1) and (3).
Reverse braking
– Braking can be accomplished by changing
the direction of travel.
– Press the reverse switch in the opposite di-
rection until the truck comes to a stop, then
release the drive switch.
Operation
4
Drive system
615001 801 1505 EN - 12/2019
