Still ECV 10 C - Page 97

Characteristics ECV 10
1.1 Manufacturer Still
1.2 Model no. ECV 10
1.3 Drive: electric, diesel, petrol, LPG, mains electric Electric
1.4 Operation Pedestrian
1.5 Nominal loading capacity Q (kg) 1000
1.6 Load centre of gravity distance
c
(mm)
600
1.8
Front overhang, distance from the vertical surface of
the forks to the centre of the front axle
x
(mm)
795
1.9 Wheelbase
y
(mm)
1240
Weight ECV 10
2.1 Service weight (with battery) kg 598
2.2 Axel load when fully loaded, drive side, load side kg 596 / 1002
2.3 Axel load when unloaded, drive side, load side kg 446 / 152
Wheels ECV 10
3.1
Tyres, drive side/load side:C=solid rubber, P=polyur-
ethane
PU/PU
3.2 Tyre size, drive side (mm) Ø210 X 70
3.3 Tyre size, load side (mm) Ø80 X 60
3.5 Number of wheels, front/rear (X = drive) 1x + 1/4
Dimensions ECV 10
4.2 Lowered mast height
h1 (mm
)
2097
4.3 Free lift height
h2 (mm
)
150
4.4 Lift height
h3 (mm
)
2927
4.5 Maximum mast height when in operation
h4 (mm
)
3487
4.9 Tiller height when driving (minimum/maximum)
h14 (m
m)
800 / 1250
4.1
5
Lowered fork height
h13 (m
m)
88
Technical data
6
ECV 10 Technical Datasheet
8950028011505 EN - 03/2022 - 06
