Still ECV 10 C - Page 98

Dimensions ECV 10
4.1
9
Overall length l1 (mm) 1740
4.2
0
Head length (without forks) l2 (mm) 590
4.2
1
Body width
b1/b2
(mm)
800
4.2
2
Dimensions of forks
s/e/l
(mm)
55 / 160 / 1150
4.2
4
Width of the fork carriage
b3
(mm)
600
4.2
5
Width across forks
b5 (mm
)
560
4.3
2
Ground clearance, centre of wheelbase, min./max.
m2 (m
m)
30
4.3
4
Aisle width, 800 x 1200 pallet, lengthwise
Ast
(mm)
2219
4.3
5
Turning radius
Wa
(mm)
1450
Performance ECV 10
5.1 Travel speed, with/without load km/h 4.5 / 4.8
5.2 Lifting speed, with/without load m/s 0.12 / 0.22
5.3 Lowering speed, with/without load m/s 0.2 / 0.13
5.8 Climbing ability, with/without load % 5 / 15
5.1
0
Brake type Electromagnetic brake
Drive ECV 10
6.1 Drive motor (60 minutes) kW 0.65
6.2 Lift motor 10% power kW 2.2
6.3 Battery to DIN 43 531/35/36 A, B, C, no -
6.4 Battery voltage/capacity (5-hour discharge) V/Ah 2 x 12 / 125
6.5 Battery weight kg 2 x 33
Other ECV 10
8.1 Control method DC
8.4 Noise level at driver's ear dB(A) 74
Technical data
6
ECV 10 Technical Datasheet
