4 Operation
Trailer operation
CAUTION
Risk of damage to components!
A support load is not permitted.
– Do not use trailers with tillers supported by the
tow coupling.
This truck is suitable for the occasional towing
of trailers. If the truck is equipped with a
towing device, this occasional towing must
not exceed 2% of the daily operating time. If
the truck is to be used for towing on a more
regular basis, the manufacturer should be
consulted.
Coupling pin in the counterweight
Coupling the trailer
DANGER
If you briefly leave the truck to couple or uncouple
the trailer, there is a risk to life caused by the truck
rolling away and running you over.
– Apply the parking brake.
– Lower the forks to the ground.
– Switchoffthekeyswitchandremovethekey.
1
7090_900-008
– Take measures to prevent the trailer from
rolling away, e.g. use wheel chocks (1).
– Push the coupling pin (2) down, turn 90°
and pull out.
232
174749 EN - 03/2017
