3 Overviews
Operating and display elements
Double mini-lever
F1
F2
7325_003-025
1
2
3
4
5
6
7
1 "Lift mast" 360° lever
2 Function key F1
3 Function key F2
4 "Drive direction/turn indicator" cross lever
5 Function key "5th function"
6 "Attachments" cross lever
7 Signal horn button
NOTE
Depending on the equipment, various electric
attachment parts can be controlled via function
keys (2) and (3). Changes must only be made
by the STILL service centre.
60 1
74749 EN - 03/2017
