SatLink VSAT User Guide
Publication no. 101557
Copyright © 2009 – STM Group, Inc.
Page 135 (160)
An overview of different antennas that can be used with the STM SatLink 403x is given in the table
below. The table shows which feed horn hole pattern (option A or B) the antenna is configured with, and
whether an adapter is required for mounting the STM SatLink 403x to the antenna feed horn. The adapter,
having model no. STM SatLink 4901, having STM P/N 107268, can be order from STM.
Manu-
facturer
Antenna Model Description Feed horn
interface
option
Ant. Size Manu-
facturer’s P/N
Adapter required
Eutel
sat
Ana
-tel
Andrew Type 960 Class I Single offset A 0.96 m 62-96051-02 No x x
Andrew Type 960 Class I Single offset B 0.96 m 62-96052-11 STM SatLink 4901 x x
Andrew Type 960 Class II Single offset A 0.96 m 62-96055-02 No x x
Andrew Type 960 Class II Single offset B 0.96 m 62-96056-01 STM SatLink 4901 x x
Andrew Type 123 Class I Single offset A 1.20 m 62-12351-02 No x x
Andrew Type 123 Class I Single offset B 1.20 m 62-12356-11 STM SatLink 4901 x x
Andrew Type 123 Class II Single offset A 1.20 m 62-12355-02 No x x
Andrew Type 123 Class II Single offset B 1.20 m 62-12362-01 STM SatLink 4901 x x
Andrew Type 184 Dual Optics B 1.80 m 62-18452-02 STM SatLink 4901 x
Andrew Type 184 Class III Single offset B 1.80 m 62-18356-01C STM SatLink 4901 x
Andrew Type 244 Dual Optics B 2.40 m 62-24452-02 STM SatLink 4901 x
Andrew Type 244 Class III Single offset B 2.40 m 62-24356-01C STM SatLink 4901 x
Patriot
TXFCC-084EL
Single offset A 0.84 m No
Patriot TXFCC-090KU Single offset A 0.90 m No
Patriot TX-INT100KU Single offset A 1.00 m No
Patriot TX-EUT100KU Dual Optics A 1.00 m No x
Patriot TX-INT120KU Single offset A 1.20 m No
Patriot TX-EUT120KU Dual Optics A 1.20 m No x
Patriot TX-EUT180KU Dual Optics A 1.80 m No x
Patriot TX-INT-240 Batwing A 2.40 m No
Prodelin 1132 Single Offset 1.2m
Prodelin 1184 Single Offset 1.8m
Prodelin 1250 Single Offset 2.4m
Visiosat 0.75m
Visiosat KIT 90 EMIT Single offset A 0.90 m 0141088 No x
Visiosat KIT 120 EMIT Single offset A 1.20 m 0141143 No x
Seatel 4003 Automatic
Polarization
Control
1.0
Seatel 2406 Orthogonal
Linear
Polarized
0.6m
Seatel 4006 Linear
Cross-Pol
and Co-Pol
1.0m
Seatel 6006 Linear
Cross-Pol or
Co-Pol
1.5m
Table 9 STM supported Ku-band antennas and feed interfaces.
Antennas with feed horn interface option B are often delivered with an OMT mounted on the feed horn.
The OMT is not needed when using the STM SatLink 403x. Remove the OMT and insert adapter STM
SatLink 4901 (STM P/N 107268) as described in Appendix G.1.
