STM SatLink 2000 - Guide

SatLink VSAT User Guide
Publication no. 101557
Copyright © 2009 – STM Group, Inc.
Page 6 (160)
1.1 About this User Guide
This User Guide covers the installation and operation of the STM SatLink 1000/1910/2000, commonly
also referred to as the indoor unit (IDU) of the DVB-RCS VSAT, together with the accompanying
outdoor unit (ODU) equipment. It is intended for DVB professionals, such as service providers and
installers. Therefore, it does not contain information for non-professional users, such as given in the user
manuals of consumer electronic products.
The information given pertains to the following STM software (SW) and hardware (HW) versions and
releases:
SatLink IDU Software
• STM SatLink Boot loader, P/N 101225, SW build 1.8.0.2 and later
• STM SatLink Boot loader, P/N 106267, version 9.0.0 and later
• STM SatLink Boot loader, P/N 120044 , Revision 14.0.0 and later
• STM SatLink DVB-RCS VSAT Software, P/N 101224, version 13.0.1 and later
• STM SatLink DVB-RCS VSAT Software, P/N 120208, version 14.0.0 and later
SatLink VSAT IDU Hardware models
• STM SatLink 100 DVB-S2 Plug-in card for SatLink 1910, P/N 107261
• STM SatLink 1000, P/N 103346
• STM SatLink 1910, P/N 103798
• STM SatLink 2000, P/N 120033
Ku-band Equipment
Transceivers
• STM SatLink 4033, P/N 104804
• STM SatLink 4035, P/N 106546
1.2 Initial Configuration
The STM SatLink VSAT IDU must be configured before it can communicate via the satellite to and from
the network Hub. The parameters to be configured are explained in section 6.2.
The configuration of the VSAT IDU can be carried out using the configuration tools:
• Web-interface (basic configuration only)
• Command Line Interface (CLI)
- Via RS232/Terminal emulator (e.g. HyperTerminal)
- Telnet
• SNMP
The SatLink VSAT Web-interface is used as the main interface for initial configuration of the VSAT
parameters and is presented in section 6. The status monitoring of the VSAT using Web interface is
presented in section 7. Configuration via CLI is presented in section 9 and management via SNMP is
presented in Appendix E. The Web interface can be used for most common configuration tasks, while
advanced configuration is only available via SNMP and CLI.
1.3 Symbols
NOTE
Additional information that the reader should pay special attention to.
WARNING
System malfunction may occur if the warning-information is violated.
