SatLink VSAT User Guide
Publication no. 101557
Copyright © 2009 – STM Group, Inc.
Page 95 (160)
19. Extensions for Mobile VSAT
The extensions in this appendix are available for the SatLink 1910 VSATs with the MOBILE software
license key set. For the transmit inhibit function described in section 19.1, additionally the SatLink 100
plug-in card, revision 2.0 or newer is required to be installed.
Below example show printout of the sw show CLI command for VSAT with the appropriate mobile
license:
#
sw show
SW versions:
Boot : 9.0.1.7
Current : 13.0.2.65
Manual SW upgrade settings:
TFTP server IP addr : 10.10.1.1
File name : new.tgz
Automatic SW upgrade settings:
Activated : Yes
Upgrade status : Waiting
PID : 1022
IP address : 224.0.1.59
Port No. : 2001
Licenses for SW options:
GRE
MOBILE
PEP-TCP
QOS-4
PEP-HTTP
VLAN
19.1 Transmit Inhibit Function
In order to comply with FCC regulations, an external push button has to be installed on Maritime
VSAT installations, making the VSAT transmitter to stop transmission within 100 ms after
pushing the push button. .
A SatLink 1910 with SatLink 100 plug-in card installed is capable of interfacing an external
push button to implement this “transmit inhibit” function,” typically being used to avoid
exposing people that has to work in the area around the antenna to the transmitted signal. When
transmit inhibit mode is cleared by releasing the external switch, the transmitter will be re-
enabled.
The transmit inhibit switch is connected to the SatLink 100 plug-in card at the two center pins of
the RJ11 connector, as shown in Figure 1 below. When short-circuited, the transmit inhibit
function is activated.
