SatLink VSAT User Guide
Publication no. 101557
Copyright © 2009 – STM Group, Inc.
Page 94 (160)
# eth primap 3 6 maps user priority 3 to internal critical data (becoming external best
effort)
# eth show
Ethernet User Priority to QoS Group mapping
Priority QoS Group
0 6
1 0
2 0
3 6
18.8 DVB-S2 16-APSK
To enable the SatLink VSAT (SatLink 1000 and 1910 Rev 3.x, and SatLink 2000) to receive 16-APSK
DVB-S2 signals there must be set the license key to configure this. Below example shows printout of the
sw show CLI command for VSAT with the appropriate DVB-S2 16APSK license:
# sw show
SW versions:
Boot : 14.0.0.16
Current : 14.0.0.14
Backup :
Manual SW upgrade settings:
TFTP server IP addr : 10.10.1.1
File name : new.tgz
Automatic SW upgrade settings:
Activated : No
PID : 511
IP address : 224.0.1.59
Port No. : 2001
Licenses for SW options:
NAT
PEP-TCP
DVBS2-16APSK
